SPC-9000 Intel® Core Ultra Processor Ultra-compact Fanless AI PC
Ruggedised -40°C to 75°C operation
- Intel® Core™ Ultra processors feature a hybrid CPU/GPU/NPU architecture, improving CPU productivity by up to 14%
- Advanced Intel® AI Boost NPU delivers 11 TOPS AI-focused performance
- Compact fanless design with -40°C to 75°C operation
- DC 9V to 55V power input with software ignition power control
- 2× USB 3.2 Gen 2, 1× USB 3.2 Gen 2x2 Type-C with DisplayPort, HDMI and DisplayPort outputs
- 2× 2.5G LAN, 3× M.2 sockets for storage and expansion
- Optional SUMIT B expansions for 10GigE LAN, 10G SFP+, or 4G networks
- Supports Intel® vPro, TSN, TCC, and TPM 2.0
- Optional VHub One-Stop AIoT Solution Service supporting OpenVINO™ toolkit for AI computing
CALL FOR PRICE
Image for illustrative purposes only
Description
The Vecow SPC-9000 is an ultra-compact fanless embedded computer powered by Intel® Core™ Ultra processors, delivering a strong balance of AI-ready performance, power efficiency and rugged industrial reliability. With a hybrid CPU/GPU/NPU architecture and integrated Intel® AI Boost NPU, the SPC-9000 is well suited to demanding edge AI, machine vision, AMR, robotics, smart retail, V2X and industrial automation applications.
Designed for deployment in harsh environments, the SPC-9000 combines wide temperature operation, a compact fanless chassis and 9V to 55V DC power input with software ignition control. Its rich I/O includes dual 2.5GigE LAN, high-speed USB 3.2, USB Type-C with DisplayPort, HDMI, DisplayPort, triple-display support and multiple M.2 sockets for storage and expansion. Optional SUMIT expansion enables further configuration with 10GigE LAN, 10G SFP+ or 4G network options, making the system highly adaptable for industrial edge computing projects.
The SPC-9000 also supports Intel® vPro, TSN, TCC and TPM 2.0, helping provide secure, manageable and time-sensitive computing for connected industrial systems. With support for Windows, Linux and OpenVINO™ AI toolkits, the SPC-9000 provides a flexible platform for developing and deploying compact, reliable AIoT solutions at the edge.
Specification
| Processor | Intel® Core™ Ultra 7 165U Processor (12 Cores), Intel® Core™ Ultra 5 135U Processor (12 Cores) |
|---|---|
| System Chipset | Intel® SoC |
| GPU | Intel® Graphics |
| Memory | 1 DDR5 5600MHz SO-DIMM, up to 48GB |
| Display Support | Supports Triple Display |
| Display | 1 HDMI 2.1 : Up to 4096x2304 @60Hz - 1 DisplayPort 1.4 : Up to 4096 x 2304 @60Hz - 1 DisplayPort 1.4 : Up to 3840 x 2160 @60Hz by USB Type-C |
| Expansion Bus | 1 SUMIT B (Optional, with customized chassis) |
| M.2 | - 1 M.2 Key B Socket (3042/3052, PCIe x2/USB 3, default/USB 2) with internal SIM - 1 M.2 Key E Socket (2230, PCIe x1/USB2) |
| Audio | 1 Mic-in, 1 Line-out |
| Status LEDs | Power, HDD, WWAN, WLAN |
| LAN | 2 x Intel® I226 2.5GigE LAN supports TSN |
| Serial Port | 2 COM RS-232/422/485 (ESD 8KV) |
| Audio Controller | Realtek® ALC888S-VD, 7.1 Channel HD Audio |
| Watchdog | Reset : 1 to 255 sec./min. per step |
| Operating System | Windows 11, Linux |
| Weight | 1.0 kg |
| Dimensions | 9000: 150.4mm x 106.2mm x 44.2mm, 9100: 150.4mm x 106.2mm x 57.0mm , 9200: 150.4mm x 106.2mm x 61.2mm |
| Operating Temperature | 9000: -40°C to 60°C with air flow, 9100: -40°C to 75°C with air flow, 9200: -40°C to 70°C with fan sink |
| Power Supply | 9V to 55VDC |
| Power | 3-pin Terminal Block：V+,V-, Frame Ground |
| SATA Storage | 1 SATA III (6Gbps) with internal 2.5" HDD/SSD bracket |
| Temperature/Fan monitoring | Monitoring temperature, voltages. Auto throttling control when CPU overheats. |
| Options | - Wallmount by mounting bracket - VESA Mount (Optional) - DIN Rail Mount (Optional) |
| EMC | CE, FCC, ICES, EN50155, EN50121-3-2 |
| Shock and Vibration | - IEC 60068-2-27 - SSD ：50G @ wallmount, Half-sine, 11ms, - IEC 60068-2-64 - SSD ：5Grms, 5Hz to 500Hz, 3 Axis |
| TPM | Infineon SLB9672 supports TPM 2.0, SPI Interface |
| USB Ports | - 1 USB 3.2 Gen 2x2 Type-C support max 20Gbps and DP 1.4 (5V/3A) - 2 USB 3.2 Gen 2 Type-A |
| Remote power on/off | 16-mode Software Ignition Control |
| SIM | 1 External Nano SIM Card Socket |
Protocols
| Primary | Secondary |
|---|
Accessories
| Product Name | Brief Description |
|---|
Downloads
- SPC-9000
Product Datasheet
